Kuom tich mar ng’ado mtoka gi pi, onge gimoro ma tiyo maber moloyo ng’ado mtoka ma nigi HORN-DRIVE. Motor ma nigi teko ma nigi pi miyo ng’ato tiyo kuom thuolo malach. Chuma motegno, gach okolo ma nigi stej ariyo mag piny kelo tich maber kendo ma nyalo geno kaachiel gi ng’wech mapiyo mar laini. Mana kaka nyithindgi matiyo gi stima, gik ma kamago luwo chike mag piny mangima mag ber kod arita.
Gigene
Motor mar pi ma nigi 80cc ma nigi teko mamalo
15000 lb nyalo, ber ne trela, gik ma ting’o gik ma ng’ato nyalo ng’ado, kod gik ma ng’ato nyalo ting’o mapek.
Brek mar Disk ma otigodo gi spring olosi
Mondo Omak Load Ma Oting’o Rate Opong’o.
Gia mar piny ma nigi step ariyo
Olosi e yo makende mondo obed mayot keto kendo onen maber.
Tich mare
Kuom lori mar tow, nyamburko mar injinia, lori, trakta, nyamburko mar ng'ado piny, nyamburko mar ng'ado lori, nyamburko mar jip, masin mar kunyo lowo, atv, utv, suv.
15000 lb ok otigodo e ting’o.
GIMO MOCHUNO
| Goyo laini opim | Kilo 6803 |
| Motor: chumbi ma nyaka chieng' | milili/r |
| Mo ma ng’ato ng’ado | Lita 5-40/dakika |
| Keto liet | MPa |
| Brek | Brek ma otomatik |
| Giya | Gia mar piny ma nigi step 2 |
| Ratio mar duoko piny gia | 27:1 |
| Klach | ma itimo gi lwedo |
| Kebo (Dia × L) | Milimita 10 × mita 24 |
| Duong' mar drum (Dia × L) | Ø3.5"×{1}}" (milimita 220) |
| Paten mar keto bolt | 10 "×4.5" (milimita 254×milimita 114.3) 4-M12 |
| Kilo mar net | Kilo 98 (kilo 44) |
Pimo mag keto
TICH MOTIMORE (layer mokwongo)
| Goro laini paundi (kilo) |
Mol G/dakika (L/dakika) |
Spido mar lain fut/dakika (m/dakika) |
| 0 | 1.3(5.0) | 1.64(0.5) |
| 4000(1814) | 2.6(10.0) | 3.6(1.1) |
| 8000(3628) | 5.3(20.0) | 7.2(2.2) |
| 12000(5443) | 9.2(35.0) | 12.4(3.8) |
| 15000(6803) | 10.6(40.0) | 16.4(5.0) |
Goro laini kod nyalo mar rope (HWN15000)
| Kidieny mar waya | Goyo laini opim paundi (kilo) |
Rope duto e wi drum fut (m) |
| 1 | 15000(6803) | 16.4 (5.0) |
| 2 | 13454(6103) | 37.2(11.3) |
| 3 | 11210(5085) | 60.9(18.6) |
| 4 | 9596(4353) | 83.7(25.5) |
